Intel FH82RM590E Platform Controller Hub

Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® ME Firmware Version
Intel® Management Engine Firmware (Intel® ME FW) uses built-in platform capabilities and management and security applications to remotely manage networked computing assets out-of-band.

Intel vPro® Platform Eligibility
The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.

Intel® Rapid Storage Technology
Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.

Intel® HD Audio Technology
Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.

Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

RAID Configuration
RAID (Redundant Array of Independent Disks) is a storage technology that combines multiple disk drive components into a single logical unit, and distributes data across the array defined by RAID levels, indicative of the level of redundancy and performance required.

Intel® Smart Sound Technology
Intel® Smart Sound Technology is an integrated digital signal processor (DSP) for audio offload and audio/voice features

Intel® Platform Trust Technology (Intel® PTT)
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.

Intel® Standard Manageability
Intel® Standard Manageability is a base set of manageability features, including: Boot Control, Power State Management, HW Inventory, Serial Over LAN, and Remote Configuration.

Intel® Stable IT Platform Program (SIPP)
The Intel® Stable IT Platform Program (Intel® SIPP) aims for zero changes to key platform components and drivers for at least 15 months or until the next generational release, reducing complexity for IT to effectively manage their computing endpoints.

Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.

Canales de memoria	Dual-channel
Código del producto	Tiger Lake
Condiciones de uso	Embedded Broad Market Extended Temp/Industrial Extended Temp
ECC	Yes
Estado	Launched
Fecha de lanzamiento	Q3'21
Número de clasificación de control de exportaciones (ECCN)	5A992CN3
Número de pantallas soportadas	4
Opciones integradas disponibles	Yes
Potencia de diseño térmico (TDP)	3,4 W
Segmento de mercado	Embedded
Sistema automatizado de seguimiento de clasificación de mercancías (CCATS)	G158870
Supported RAID configuration	PCIe 0,1,5 / SATA 0,1,5,10
Supports overclocking	No
System bus rate	8 GT/s
Tamaño del paquete	25 x 24 mm
Tarjeta gráfica integrada	No
Estándar Wi-Fi superior	Wi-Fi 5 (802.11ac)
Wi-Fi	Yes
Maximum number of PCI Express lanes	24
Número de conectores SATA III	8
PCI Express configurations	1x16+1x4/1x8+3x4/2x8+1x4
Puertos USB	14
Versión ranuras PCI Express	3.0
Versión USB	2.0/3.2 Gen 2 (3.1 Gen 2)
Intel ME Firmware Version	15
Intel Stable Image Platform Program (SIPP)	Yes
Intel Standard Manageability	Yes
Intel® Boot Guard	Yes
Intel® High Definition Audio (Intel® HD Audio)	Yes
Intel® Optane™ Memory Ready	No
Intel® Platform Trust Technology (Intel® PTT)	Yes
Intel® Stable IT Platform Program (SIPP)	Yes
Intel® vPro™ Platform Eligibility	Yes
Tecnología de almacenamiento rápido Intel	Yes
Tecnología Intel de virtualización para E/S dirigidas (VT-D)	Yes
Tecnología Intel Trusted Execution	Yes
Tecnología Intel® Smart Sound	Yes
Garantía	1 año
