Xeon Gold 6434 Processor 3.7

Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Cache
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Crypto Acceleration
Intel® Crypto Acceleration reduces the performance impact of pervasive encryption and increases the performance of encryption-intensive workloads including SSL web serving, 5G infrastructure, and VPN/firewalls.

Intel® Software Guard Extensions (Intel® SGX)
Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications’ sensitive routines and data. Intel® SGX provides developers a way to partition their code and data into CPU hardened trusted execution environments (TEE’s).

Intel® Speed Select Technology – Core Power
Enables flexibility for workloads that benefit from higher base frequency on a subset of the processor’s cores. While the max turbo frequency across the cores remain constant across the cores, a subset of the cores can be assigned as to run at a higher base frequency than specified, while the other cores run at lower base frequency.

Condiciones de uso	Server/Enterprise
Conjuntos de instrucciones compatibles	AMX/AVX/AVX 2.0/AVX-512/SSE4.2
Ejecutar bit de desactivación	Yes
Escalabilidad	2S
Máximo número de carriles PCI Express	80
Número de clasificación de control de exportaciones (ECCN)	5A992C
Opciones integradas disponibles	No
Segmento de mercado	Server
Sistema automatizado de seguimiento de clasificación de mercancías (CCATS)	G180729
Versión ranuras PCI Express	5.0
Modelo de tarjeta gráfica discreta	Not available
Modelo de tarjeta gráfica integrada	Not available
Tarjeta gráfica discreta	No
Tarjeta gráfica integrada	No
Canales de memoria	Octa-channel
ECC	Yes
Máxima memoria interna soportada por el procesador	6 TB
Tipos de memoria compatibles con el procesador	DDR4-SDRAM
DTS Max	96 °C
Tcase	64 °C
Máxima memoria interna	4 TB
Caché del procesador	22,5 MB
Caja	No
Cógido del procesador	Sapphire Rapids
Enchufe procesador	LGA 4677 (Socket E)
Escalonamiento	S3
Fabricante procesador	Intel
Familia procesador	Intel® Xeon® Gold
Frecuencia base del procesador	3,7 GHz
Frecuencia de aumento del procesador	4,1 GHz
Frecuencia de núcleo de alta prioridad	3,9 GHz
Generación procesador	Intel Xeon Scalable 4th Gen
Modelo procesador	6434
Modos de funcionamiento del procesador	64-bit
Núcleos de alta prioridad	2
Núcleos de baja prioridad	6
Núcleos procesador	8
Tipo de paquete	Tray
Potencia de diseño térmico (TDP)	195 W
Procesador ARK ID	232375
Subprocesos procesador	16
Velocidad bus del sistema	16 GT/s
Intel 64	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Advanced Matrix Extensions (AMX)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Boot Guard	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Crypto Acceleration	Yes
Intel® Data Streaming Accelerator (DSA)	1 default devices
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® On Demand Feature Activation	Yes
Intel® OS Guard	Yes
Intel® Platform Firmware Resilience Support	Yes
Intel® QuickAssist Software Acceleration	Yes
Intel® Total Memory Encryption	Yes
Intel® Transactional Synchronization Extensions	Yes
Máxima compatibilidad con el tamaño del enclave para Intel ® SGX	128 GB
Tecnología de memoria persistente Intel® Optane™ DC	Yes
Tecnología de virtualización Intel (VT-x)	Yes
Tecnología Intel de virtualización para E/S dirigidas (VT-D)	Yes
Tecnología Intel Trusted Execution	Yes
Tecnología Intel® Speed Shift	Yes
Tecnología Intel® Turbo Boost	2.0
Unidades AVX-512 FMA (Fm) fusionadas	2
Estado	Launched
Fecha de lanzamiento	Q1'23
Número de enlaces UPI	3
Package carrier	E1B
Tipos de memoria admitidos	DDR4-SDRAM
Velocidad de memoria (máx.)	4800 MHz
Garantía	1 año
Tamaño del paquete del procesador	77.5 x 56.5 mm
