Xeon Gold 6138 2.0GHz 20C - Ref. CD8067303406100-RFB

Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Cache
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel vPro® Platform Eligibility
The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.

Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

Intel® Run Sure Technology
Intel® Run Sure Technology, includes advanced RAS (reliability, availability and serviceability) features that deliver high reliability and platform resiliency, to maximize uptime of servers running mission-critical workloads.

Intel® Turbo Boost Max Technology 3.0
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

Max # of UPI Links
Intel® Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel® QPI.

# of AVX-512 FMA Units
Intel® Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.

Intel® Volume Management Device (VMD)
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Mode-based Execute Control (MBEC)
Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

Intel® Transactional Synchronization Extensions
Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.

Conjuntos de instrucciones compatibles	AVX-512
Ejecutar bit de desactivación	Yes
Escalabilidad	S4S
Máximo número de carriles PCI Express	48
Número de clasificación de control de exportaciones (ECCN)	5A992C
Opciones integradas disponibles	Yes
Revisión PCI Express CEM	3.0
Segmento de mercado	Server
Sistema automatizado de seguimiento de clasificación de mercancías (CCATS)	G077159
Versión ranuras PCI Express	3.0
Tarjeta gráfica integrada	No
Canales de memoria	Hexa-channel
ECC	Yes
Máxima memoria interna soportada por el procesador	768 GB
Tipos de memoria compatibles con el procesador	DDR4-SDRAM
Velocidades de reloj de memoria compatibles con el procesador	2666 MHz
Tcase	86 °C
Máxima memoria interna	786432 MB
Máxima memoria interna	768 GB
Caché del procesador	27,5 MB
Caja	No
Código del procesador	SR3B5
Cógido del procesador	Skylake
Componente para	Server/workstation
Enchufe procesador	LGA 3647 (Socket P)
Escalonamiento	H0
Fabricante procesador	Intel
Familia procesador	Intel® Xeon® Gold
Frecuencia base del procesador	2 GHz
Frecuencia de aumento del procesador	3,7 GHz
Generación procesador	1st Generation Intel® Xeon® Scalable
Litografía del procesador	14 nm
Modelo procesador	6138
Modos de funcionamiento del procesador	64-bit
Núcleos procesador	20
Tipo de paquete	Tray
Potencia de diseño térmico (TDP)	125 W
Procesador ARK ID	120476
Refrigerador incluido	No
Subprocesos procesador	40
Tipo de caché del procesador	L3
Intel 64	Yes
Intel TSX-NI	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel versión TSX-NI	1.00
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Optane™ Memory Ready	No
Intel® Transactional Synchronization Extensions	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® vPro™ Platform Eligibility	Yes
Procesador libre de conflictos	Yes
Tecnología de virtualización Intel (VT-x)	Yes
Tecnología Intel de virtualización para E/S dirigidas (VT-D)	Yes
Tecnología Intel SpeedStep mejorada	Yes
Tecnología Intel Trusted Execution	Yes
Tecnología Intel® Speed Shift	Yes
Tecnología Intel® Turbo Boost	2.0
Unidades AVX-512 FMA (Fm) fusionadas	2
Caché del procesador	28160 KB
End of servicing updates date	Sunday, December 31, 2023
Estado	Launched
Familia de productos	Intel Xeon Processors
Fecha de lanzamiento	Q3'17
Intel® Run Sure Technology version	1.00
Intel® Volume Management Device (VMD) version	1.00
Marca del procesador	Intel Xeon Gold/Intel Xeon Gold Processor
Máxima memoria	768 GB
Número de enlaces UPI	3
Servicing status	ESU Notification Issued
Tipo de producto	Processor
Tipos de memoria admitidos	DDR4-SDRAM
Último cambio	63903513
Velocidad de memoria (máx.)	2666 MHz
Versión Intel® Speed Shift Technology	1.00
Versión modo basado en control de ejecución (MBE)	1.00
Garantía	1 año
Tamaño del paquete del procesador	76mm x 56.5mm mm
